Description
Features:
Compact, cordless motor with a built-in apex locator
A Motor for Apical Patency, Glide Path, and Shaping
It can be used for obtaining apical patency and creating a glide path using rotary instrumentation. Rotary files even as Small as #10 may be used for these procedures. Responsive, the handpiece allows subtle and delicate manipulation of the file, corresponding to the movements of an experienced dentist's hand. Tri Auto ZX2 also offers improved safety and efficiency during canal shaping.
Clinical images are provided by Dr. Yoshi Terauchi / Dr. Toshihiro Ushikubo / Dr. Tai Gega
Achieve apical patency and create a glide path
OGP Function (Optimum Glide Path)
Using #20 or smaller files, the motor can be used to achieve apical patency and create a glide path. It reproduces the subtle and delicate finger movements of an experienced dentist.
Even curved or constricted canals can be treated faster and more safely. Both NiTi files sized #20 or smaller, or stainless steel files sized #15 or smaller may be used.
Improved safety and efficiency during canal shaping
OTR Function (Optimum Torque Reverse)
Depending on the load on the file, the motor alternates between forward and reverse rotation with exceptional sensitivity to greatly reduce the chance of jamming or file breakage. It is also superior in its ability to follow the shape of even curved canals to reduce ledges and perforation. Tri Auto ZX2 is compatible with standard NiTi files - no need to purchase specialty files.
Automatic Stop Safety Feature
The Tri Auto ZX2 motor is linked with the apex locator function. This feature makes endodontic treatment safer and more efficient. The position of the file tip inside the canal is shown in the display, and the motor stops or reverses rotation as soon as the file reaches the end of the working length to reduce the chance of perforation. Also, the auto start and stop function automatically starts the motor when the file is inserted into the canal and stops it when it is removed.
Specification
| Name: | Tri Auto ZX2 |
| Model: | TR-ZX2 |
| Manufacturer: | J. MORITA MFG. CORP. |
| Functions: | Root Canal Module |
| OGP (Optimum Glide Path) | |
| OTR (Optimum Torque Reverse) | |
| OAS (Optimum Apical Stop) | |
| Auto Start / Stop | |
| Auto Torque Reverse | |
| Auto Apical Reverse / Stop | |
| Auto Apical Slow Down | |
| Auto Apical Slow Down | |
| Auto Torque Slow Down |
| Accessories: | Tester, Spray Nozzle |
| Options: | LS Spray, Handpiece Holder, |
| External File Electrode (with cap) |
Handpiece
| Free Running Operation Speed: | 100 ± 20 - 1000 ± 100 rpm |
| Torque: | 4 Ncm or more |
| Battery: | Lithium-ion battery (DC 3.7 V) |
| Weight: | Approx. 140 g (including battery and contra angle) |
Battery Charger
| Rated Input Voltage: | DC 5 V |
| Rated Input Current: | 2.4 A |
| Weight: | Approx. 280 g (AC adapter not included) |
AC Adapter
| Rated Input Voltage: | AC100 - 240 V |
| Rated Input Frequency: | 47 - 63 Hz |
| Rated Input Current: | 0.4 A |
